Electric Linear Actuator

​ELA45  Heavy Model 7000N

Ball Screw| Planetary Gearbox | IP68
Overload Protection|Stroke Setting​

ELA45 STP File Download

Overview

ELA45 series is the ideal model to replace your current hydraulic system and suitable for heavy duty operation.


The compact tubular design integrating high efficient ball-screw transmission and durable brush motor makes everything simple and neat.


Built-in over current detection (OCD) unit provides users with extra proactive safety measure.


Accessories such as external reed switch, limit switch, remote controller, control box and power supply are optional.

electric linear actuator over current detection unit

Over Current Detection (OCD)

OCD unit monitors the status of current at all times. When it reaches stroke limit or encounters any blockage on its way, the OCD unit shuts motor down proactively to prevent it from burning out.

Taiwan Invention Patent No: I671995

US Patent No: US10630214B2 DC Motor Controller

ELAXX Reed Switch Setting02.jpg

Stroke Setting

Sometimes the existing product does not fit perfectly with your demand. For example, you could hardly find an actuator with stroke 170mm from the market but that is what you actually need.

Not a problem, just connect our actuator with external reed switches, adjust the stroke, and everything is done.


Work With Reed Switches

Function S: Stroke setting, 1 set of wiring (2 wires) each for the upper and lower limits. It can be connected to A-contact switches, such as reed switches, limit switches, push switches, tact switches, etc.

Function RStroke setting, 1 set of wiring (2 wires) each for the upper and lower limits. The reed switch has been connected, and the cylinder piston has a built-in magnetic ring. The position of the piston can be sensed when the reed switch is close.

ELA Linear Actuator Features20_HURD.jpg

​Product Code

ELA45 - XXX - XXX - 24 - X

                 Stroke   Load   Voltage  Function

Please kindly indicate your demand with the above coding principle while contacting us, thanks.

Scope of Application

Patients could adjust angles on their heads, backs and legs into an ideal position to alleviate any discomfort caused by pain.



It also reduces the burden on the waist of the nursing staff.

Electric Medical Bed

An assistive device that will help a caregiver transfer a patient, with limited mobility, from one place to another.

Patient Lift

For tripods or kickstands.



With two electric linear actuators and a sync. PCB, parking is easy and elegant.

Motorcycle

For electric tailgates, electric lift bike racks and wheelchair lift and ramp system.

Vehicle

According to the different angles of sunlight incidence, the sun's azimuth and elevation angles are tracked throughout the day to collect the maximum amount of solar radiation so as to obtain the best power generation efficiency.

Solar Tracking System

=

Elevating Kitchen Counter
